Claytools
    32位系統(tǒng)要

Running the ClayTools 32-bit requires an Intel-based workstation with the following:

• 150 MB of free hard disk space
• 1280 x 960 or higher display resolution
• IEEE-1394a compatible FireWire? Card*
• PHANTOM Device Driver v4.2.68 or later

* The PHANTOM Omni device is IEEE 1394a compliant. However, SensAble is aware of

customers that have experienced difficulties. See?Important Notes?below for more

 information.Additionally, your machine must meet either the recommended or minimum requirements:

• Intel Pentium dual 2.8 GHz
• 2 GB of RAM
• NVIDIA? FX1100 or better graphics card
• WindowsXP Professional SP2

最低系統(tǒng)配置:

• One of the following: Intel? single 2.0 GHz; Intel Dual 933 MHz; Intel? Core? Duo
processor

• 1 GB RAM
• A qualified graphics card
• Windows? 2000 SP3 or SP4; Windows XP Professional SP1, SP1A, or SP2

    Claytools
    64位系統(tǒng)要求

Running the ClayTools 64-bit system requires an AMD64-based workstation with the

following:

• 10 GB of free hard disk space
• 1280 x 960 or higher display resolution
• IEEE-1394a compatible FireWire Card*
• PHANTOM Device Driver v4.2.73 or later

* The PHANTOM Omni device is IEEE 1394a compliant. However, SensAble is

aware of

customers that have experienced difficulties. See?Important Notes?below for more

 information.

• (2) AMD64 Opteron 248 2.2GHz processors w/1GHz HyperTransport
• 4GB DDR2-400 RAM
• NVIDIA Quadro FX 540 128MB PCIe graphics card
• 80GB SATA 7200 RPM Hard Drive
• Microsoft Windows XP Professional x64 Edition

    廠家認證的64位配置

SensAble has tested and qualified the following specific configurations. Choosing one of

these configurations will ensure the best possible experience when running the FreeForm

64-bit Edition.

HP xw8400 Workstation with (2) Intel Dual-Core Xeon 5150/ 2.66 GHz, 4MB L2, 1333 MHz

 FSB4 GB FBD DDR2 – 667MHz RAM

• 80GB SATA NCQ
• NVIDIA Quadro FX 5500/FX 4500
• Windows XP Professional x64

HP xw6400 Workstation with (2) Intel Dual-Core Xeon 5150/ 2.66GHZ DC B0

• 4GB FBD – 667MHz RAM
• 73GB 15K RPM SAS Hard Drive
• NVIDIA Quadro FX 1500
• Windows XP Professional x64

HP xw9300 Workstation with (2) 64-bit AMD Opteron? 252 2.6 GHz processors

with 1GHz-HT

• 8GB DDR2-400MHz RAM
• 74GB SATA 10,000 RPM Hard Drive
• NVIDIA Quadro FX3450 256MB PCIe
• Windows XP Professional x64
